SIZE : W9200 x D2400 x H3200

WEIGHT : 8500Kg

Tape size : Inside Diameter Minimum à  25mm

              Tape width à  10 ~ 25mm

Tape overlap : 0.1 ~ 25mm

Taping speed : Coil slot Maximum 300rpm/min

                    Corona Maximum 150rpm/min

Coil clamps : Air clamping

Control axis : Control Axis-13

                   X.Y.Z.S.T.C.CL.CR.B.BC1.BC2.BC3.BC4 - Axis

Control system: Control system ,Motion system, PLC system

Power supply : Three-phase 220V/380V/440V

Air pressure : 0.5 ~ 0.8Mpa (Clamps by the air cylinder)

Option : Additional lower coil clamps

** Programs can be saved to the memory **
