SIZE : W4200 x D2100 x H2640

WEIGHT : 4500Kg

Tape size : Inside Diameter Minimum à 25mm

              Tape width à  9 ~ 25mm

Tape overlap : 0.1 ~ 25mm

Taping speed : Coil slot Maximum 300rpm/min

Coil clamps : Air clamping

Control axis : Control Axis-5

                  X.Y.S.T-Axis + Z-Axis support

Control system : Control system ,Motion system, PLC system

Power supply : Three-phase 220V/380V/440V

Air pressure : 0.5 ~ 0.8Mpa (Clamps by the air cylinder)
